What Do You Get With The Sawgrass SG1000 Dye Sublimation Printer ?

1 x Sawgrass SG1000 A3 Sublimation Printer
1 x Sublijet UHD Black Cartridge (20ml, 31ml or 70ml)
1 x Sublijet UHD Cyan Cartridge (20ml, 31ml or 70ml)
1 x Sublijet UHD Magenta Cartridge (20ml, 31ml or 70ml)
1 x Sublijet UHD Yellow Cartridge (20ml, 31ml or 70ml)
1 x MySawgrass Design - (cloud based)
1 x MySawgrass Print Utility
1 x Power Cable
1 x 100 sheets Sawgrass Truepix A3 sublimation paper

There are 3 options for cartridges, you can get Starter Inks (20ml per cartridge), Full Capacity Inks (31ml per cartridge) or Extended Capacity Inks (70ml per cartridge)

The Sawgrass SG1000 is a desktop A3 dye sublimation printer.

Dye sublimation is a process where you print your artwork using special inks onto special paper. You then apply this to specially receptive products, eg garments or mug using a heat press. At the correct temperature the ink turns into a gas and fuses into the product, giving a long lasting, vibrant image.

High Definition Printing
The SG1000 printers are the the only printers designed specifically for sublimation printing. Using the Sawgrass SubliJet-UHD inks, the SG1000 printer delivers the highest resolution prints possible for vibrant, ultra fine photo quality reproduction at up to 4880 x 1200 dpi.
Using a multi cartridge ink system (black, magenta, cyan and yellow), the SG500 printer driver unleashes up to to 687,754 colours out of just those 4 cartridges and the new UHD inks gives deeper black than any other ink before.
Faster Speeds, Greater Productivity
The SG1000 is over twice as fast than their Ricoh predecessors and 50% faster than the SG400, meaning you can print up to 240 prints per hour. The printer has a built in self cleaning routine ensuring that the printer is running at its optimal performance.
Wi-Fi
The SG1000 comes as a wifi enabled printer, no longer restricting you to the length of your USB cable.
Easy Expansion Options
The optional Bypass Tray extends maximum media size up to 330x1295mm (13x51 inch).
Service and Support
All Sawgrass systems come with access to PartnerPlus, Sawgrass's comprehensive user support program which offers real time help with system troubleshooting and assistance with colour management software.
Warranty
All Sawgrass Desktop HD Product Decorating Systems come with a two year warranty in the UK and EU.
Whilst you can use the Sawgrass dye sublimation printer with an existing software package such as Corel or Photoshop, Sawgrass printers come bundled with the feature rich MySawgrass software.
MySawgrass Design
Designed specifically for use with Sawgrass printers your creative companion is on hand to make the design process simple. The interface allows for-
*Print-Ready Products, browse trending & best-selling product templates formatted for sublimation.
*Upload your own templates
*Intuitive Customization, easily create & customize artwork perfectly sized for your print project.
*Real-Time Preview, see your changes come to life instantly & create post-ready mockups in a click.
*Ability to draw basic shapes
The design tool accepts multiple file types: JPG, PNG, SVG, AI, PSD, PDF and CDR.
MySawgrass Print Utility
Print Utility is your printing companion, designed to make your printing process more efficient, accurate, and flexible. Simple to instal and with automatic updates Print Utility will help enhance your workflow with-
*Print from anywhere, send and print from any application
*Maximise paper use, organise multiple prints on a single sheet
*Spot colour replacement
*Excellent print job limitations, meaning you can handle larger and more complex projects
The new integrated Silhouette cutter means a seamless integration with Silhouette cutting machines. MySawgrass Print Utility allows you to take control of your printing process.
MySawgrass also gives you access to free education, inspiration, and a global community.

Specification

General Specifications

Maximum Media Size

297x431mm sheet. Standard A3 sized media
215x1295mm with optional bypass tray

Display Panel

LCD

Interface

WiFi / USB 2.0 High Spee

Voltage

220 / 240v

Warranty

2 year return to base parts and labour

Unit Dimensions

529(w) x 360(d) x 213(h)mm

Unit Weight

16Kg

Box Dimensions

700(w) x 550(d) x 340(h)mm

Consumables

The printer is sold with a complete set of full capacity cartridges.

Replacement Consumables

RSYSSG6450 Sawgrass Waste Ink Tank

Standard Capacity Ink

609101 Sawgrass SG500 Sublijet UHD 31ml Black

609102 Sawgrass SG500 Sublijet UHD 31ml Cyan

609103 Sawgrass SG500 Sublijet UHD 31ml Magenta

609104 Sawgrass SG500 Sublijet UHD 31ml Yellow

Extended Capacity Ink

609231 Sawgrass SG1000 Sublijet UHD 70ml Black

609232 Sawgrass SG1000 Sublijet UHD 70ml Cyan

609233 Sawgrass SG1000 Sublijet UHD 70ml Magenta

609234 Sawgrass SG1000 Sublijet UHD 70ml Yellow

Print Speeds and Resolutions

High Speed

15 seconds (600x600 dpi)

High Quality

29 seconds(600x600 dpi)

Advance Photo

48 seconds (1200x1200 dpi)

Ultra Fine Photo

6 minutes 40 seconds (4880x1200 dpi)

Colour Management Options for Desktop Graphic Software

PowerDriver 4.2 OS Recommendations*

Windows 7, 8 Professional, Business, Enterprise, Ultimate

Mac Profile OS

Recommendations* Mac OS 10.9 or later

Graphics Application Recommendations*

Corel: CorelDraw X6 or Later / Adobe: Illustrator and Photoshop CS6 or Creative Cloud, Photoshop Elements 12 and Later

*Visit sawgrassink.com for a complete list of supported PowerDriver 4.2 OS and graphic software.

MySawgrass Software

Windows 8 or Mac 10.13 computer equipped with either an Intel or AMD processor.

Internet connection is required during the installation process of the software.

Power Supplies (UK and Euro Style Available)

All UK and Republic of Ireland orders are despatched with a UK 3 Pin plug power supply.

For all countries outside the UK and Republic of Ireland we will despatch your machine with a European 2 Pin power supply unless you specifically request the UK 3 Pin plug power supply.
